Introduction to OvenSENTINEL™

OS_Logo_Icon

Welcome to the OvenSENTINEL™ Help Guide! Choose a topic from each topic to find answers and get an overview plus step-by-step instructions.

Help Guide

This OvenSENTINEL™ Help Guide explains how to use the ECD OvenSENTINEL™ Intelligent Monitoring Solution System and software.

Declaration of Conformity

The undersigned hereby declares, on behalf of the ECD Inc., that the above-referenced product, to which this declaration relates, is in conformity with the provisions

Graphic Symbols

OvenSENTINEL™ and this Help Guide use graphic symbols which help identify at a glance several Dangers, warnings, functions, as well as indicate the status of the cabinet.

Information that protects the exclusive right to make copies, license, and otherwise exploit any portion of this Help Guide.

Operator Safety Information

The safety information in this section is for the benefit of operating personnel. Warnings and Cautions will also be found throughout the manual where they apply.

LEARN MORE î

How to use this Help Guide

This Guide is written for users of varied experience. If a section covers information you already know, feel free to skip to the next section.

•You do not need to be a computer expert to use this manual or the software.

•The Users Help Guide assumes you are familiar with Microsoft® Windows®.

Graphic Symbols

Product Symbols:

	Warning: Whenever this internationally recognized symbol is used on the product, additional information concerning that particular feature or function appears in the Help Guide.
	Waste Electrical and Electronic Equipment (WEEE). Unit should be recycled; Do not disposed of in land-fill.
	Warning: Electrical Shock / Electrocution Hazard.
	Positive Polarity
	Direct Current (DC) Power
	Alternating Current (AC) Power
	Conformity marking for certain products sold within the European Economic Area (EEA)
	Moves the control display menu cursor up or increments a user entered value.
	Moves the display menu cursor down or decrements a user entered value.
	Selects the current highlighted menu item in the display or approves a user set value.

Help Guide Symbols:

	Informs the user that the note includes important information.
	Informs the user that the note includes a handy tip.
	Informs the user of an equation used.

	Informs the user that the note identifies conditions or practices that could result in damage to the equipment.
	Informs the user that the note identifies conditions or practices that could result in personal injury or damage to property other than the equipment.

Operator Safety Information

Hardware changes or modifications to the components are not expressly approved by ECD. and could void the warranty of the product.

Symbol_(Caution)

The warranty will not cover damage caused by neglect or abuse of this product. To maintain the safety features incorporated in this product, operation must be in strict compliance with the requirements specified herein.

For protection of the components, observe the following:

Symbol_(Caution)

•NEVER operate the OvenSENTINEL™ components in flammable or explosive atmospheres. Such usage constitutes a fire or explosion risk.

•NEVER immerse the OvenSENTINEL™ components in liquids.

•NEVER subject the OvenSENTINEL™ components to sharp impacts.

•NEVER excessively stress the OvenSENTINEL™ cables.

•NEVER expose the OvenSENTINEL™ components to corrosive environments.

Symbol_(Caution)

Battery Warnings:

•Replace the batteries with same type only. Real-Time Clock/Memory Backup Battery: 3.6V 1.2Ah cell, LS14250 (ANSI 1/2AA, IEC 1/2R6) by Saft or equivalent. Using alternate batteries may present a risk of fire or equipment damage.

•Do not attempt to recharge the Real-Time Clock/Memory Backup Battery, disassemble, or dispose of in fire. Always dispose of used batteries promptly and properly.

•Do not expose to temperature above 100°C (212°F).

•Keep the batteries away from children.

•The batteries may explode if mistreated.

•The batteries contain electrolytes.

Declaration of Conformity

	Electronic Controls Design, Inc.
	4287-B S.E. International Way
	Milwaukie, Oregon U.S.A. 97222-8825
	(503) 659-6100 / (800) 323-4548
	FAX: (503) 659-4422

Declaration of Conformity

OvenSENTINEL™ Station

E58-6928-42

The undersigned hereby declares, on behalf of the ECD Inc., that the above-referenced product, to which this declaration relates, is in conformity with the provisions of:

SAFTEY:

IEC 61010-1 “Safety requirements for electrical equipment for measurement, control, and laboratory use - Part 1: General requirements”

EMISSIONS:

EN 61000-3-2:2014 “Electromagnetic Compatibility (EMC) - Limits For Harmonic Current Emissions …”

EN 61000-3-3:2013 “Electromagnetic Compatibility (EMC) - Limitation of voltage changes, voltage fluctuations and flicker …”

EN 61000-6-4:2007+A1:2011 Class A “Electromagnetic compatibility (EMC) - Emission standard for industrial environments”

FCC 15.107:2015 Class A “Conducted Limits”

FCC 15.109(g):2015 Class A “Radiated emission limits”

ICES-003:2012 Class A “Information Technology Equipment (ITE) – Limits”

IMMUNITY:

EN 61000-6-1:2007 “Electromagnetic Compatibility (EMC). Immunity for residential, commercial and light-industrial environments”

The Technical Construction File required by this Directive is maintained at the corporate headquarters of ECD, Inc.
Name:	Todd Clifton
Position:	President & CEO
Signature:
Date:	July, 2019

Copyright

©2023 ECD. All Rights Reserved. Printed in USA. US Products of ECD are covered by foreign and US Patents and Patents Pending. Information in this publication supersedes all previously published information. This Publication may not be translated and/or reproduced or stored in data retrieval system, or transmitted in any form or by any means without the express written permission of ECD. Specification and price change privileges reserved.

While every precaution has been taken in the preparation of this document, ECD assumes no responsibility for errors or omissions, or for damages resulting from the use of information contained in this document or from the use of programs and source code that may accompany it. In no event shall ECD be liable for any loss of profit or any other commercial damage caused or alleged to have been caused directly or indirectly by this document.
