Weight & Dimensions:

Length (Pallet)

452 mm [17.8 in]

452 mm [17.8 in]

452 mm [17.8 in]

Height (Thermal Barrier)

31.75 mm [1.25 in]

31.75 mm [1.25 in]

31.75 mm [1.25 in]

Width

168mm (6.6 in)

305mm (12 in)

457mm (18 in)

Weight

1.74 kg [3.84 lb]

2.81 kg [6.19 lb]

3.54 kg [7.8 lb]

Maximum Operational Temperature:

Pallet:

280C [536F] continuous, 300C [572F] maximum

Thermal Barrier:

204°C (400°F) for 25min. / 260°C (500°F) for 15min.

Pallet Sensors:

Type:

6 Type K (Process & Ambient)

Special Limits of Error K-Type T/C wire

(± 1.1°C or 0.4%, whichever is greater)

Data Capacity:

SuperM.O.L.E.™ Gold 2:

2,500 minutes (100% memory)

SuperM.O.L.E.™ Gold:

9 minutes 6 seconds

Construction:

Country of Manufacturing

USA

Zone Magnets:

Material:

Alnico

Weight:

0.3 oz

Length:

0.29cm (0.75 in)

Diameter:

0.15cm (0.375 in)

Maximum Operating Temperature:

482°C (900°F)

Open circuit gauss:

800 +/-100

The information contained herein is subject to change without notice
